產品簡介

BATOP 現已成為用于被動鎖模激光器的可飽和吸收體的優秀的供應商。可飽和吸收產品集合了各式各樣的不同的器件，從可飽和吸收鏡(SESAM)，到可飽和輸出鏡(SOC)和用于透過應用的可飽和吸收體(SA)。迄今為止，可飽和吸收產品已經覆蓋了800nm到2.6μm的常用激光波長范圍。

SAM? - saturable absorber mirror λ = 1645 nm

product list λ = 1645 nm (1560 nm ... 1670 nm)

Part No. help	Description	Data PDF
SAM-1645-2-2ps-x	SAM: λ = 1645 nm, absorbance 2 %, Δ R = 1.2 %, relaxation time ~ 2ps
SAM-1645-4-2ps-x	SAM: λ = 1645 nm, absorbance 4 %, Δ R = 2.4 %, relaxation time ~ 2ps
SAM-1645-5-2ps-x	SAM: λ = 1645 nm, absorbance 5 %, Δ R = 3 %, relaxation time ~ 2ps
SAM-1645-8-2ps-x	SAM: λ = 1645 nm, absorbance 8 %, Δ R = 5 %, relaxation time ~ 2ps
SAM-1645-32-2ps-x	SAM: λ = 1645 nm, absorbance 32 %, Δ R = 20 %, relaxation time ~ 2ps
SAM-1645-50-2ps-x	SAM: λ = 1645 nm, absorbance 50 %, Δ R = 30 %, relaxation time ~ 2ps
PHS	passive heat sink for fiber coupled SAM

SAM? - saturable absorber mirror λ = 2000 nm

product list λ = 2000 nm (1900 nm ... 2050 nm)

broadband SAM 1700 nm - 2150 nm

Part No. help	Description	Data PDF
SAM-2000-2-10ps-x	SAM: λ = 1700 nm - 2150 nm, absorbance 2 %, Δ R = 1.2 %, relaxation time ~ 10 ps. This SAM can be only glued on a copper heat sink, but not soldered

SAMs 1920 nm

Part No. help	Description	Data PDF
SAM-1920-2-30ps-x	SAM: λ = 1920 nm, absorbance 2 %, Δ R = 1.2 %, relaxation time ~ 600 fs and ~ 34 ps
SAM-1920-4-30ps-x	SAM: λ = 1920 nm, absorbance 4 %, Δ R = 2.6 %, relaxation time ~ 600 fs and ~ 40 ps
SAM-1920-7-10ps-x	SAM: λ = 1920 nm, absorbance 7 %, Δ R = 4 %, relaxation time ~ 10 ps
SAM-1920-8-10ps-x	SAM: λ = 1920 nm, absorbance 8 %, Δ R = 5 %, relaxation time ~ 10 ps
SAM-1920-36-10ps-x	SAM: λ = 1920 nm, absorbance 36 %, Δ R = 20 %, relaxation time ~ 10 ps
passive heat sink	passive heat sink for fiber coupled SAM

SAMs 1960 nm

Part No. help	Description	Data PDF
SAM-1960-5-10ps-x	SAM: λ = 1960 nm, absorbance 5 %, Δ R = 3 %, relaxation time ~ 10 ps
SAM-1960-8-10ps-x	SAM: λ = 1960 nm, absorbance 8 %, Δ R = 5 %, relaxation time ~ 10 ps
SAM-1960-13-10ps-x	SAM: λ = 1960 nm, absorbance 13 %, Δ R = 8 %, relaxation time ~ 10 ps
SAM-1960-15-10ps-x	SAM: λ = 1960 nm, absorbance 15 %, Δ R = 8 %, relaxation time ~ 10 ps
SAM-1960-18-10ps-x	SAM: λ = 1960 nm, absorbance 18 %, ΔR = 10 %, relaxation time ~ 10 ps, for fiber laser mode-locking
SAM-1960-30-10ps-x	SAM: λ = 1960 nm, absorbance 30 %, ΔR = 18 %, relaxation time ~ 10 ps, antiresonant design for fiber laser mode-locking
SAM-1960-54-10ps-x	SAM: λ = 1960 nm, absorbance 54 %, Δ R = 30 %, relaxation time ~ 10 ps, resonant design for fiber laser mode-locking
passive heat sink	passive heat sink for fiber coupled SAM

SAMs 2000 nm

Part No. help	Description	Data PDF
SAM-2000-13-10ps-x	SAM: λ = 2000 nm, absorbance 13 %, Δ R = 8 %, relaxation time ~ 10 ps
SAM-2000-20-10ps-x	SAM: λ = 2000 nm, absorbance 20 %, Δ R = 12 %, relaxation time ~ 10 ps, antiresonant resonant design for fiber laser mode-locking
SAM-2000-30-10ps-x	SAM: λ = 2000 nm, absorbance 30 %, Δ R = 18 %, relaxation time ~ 10 ps, antiresonant resonant design for fiber laser mode-locking
SAM-2000-36-10ps-x	SAM: λ = 2000 nm, absorbance 36 %, Δ R = 20 %, relaxation time ~ 10 ps, resonant design for fiber laser mode-locking
SAM-2000-43-10ps-x	SAM: λ = 2000 nm, absorbance 43 %, Δ R = 25 %, relaxation time ~ 10 ps, resonant design for fiber laser mode-locking
SAM-2000-44-10ps-x	SAM: λ = 2000 nm, absorbance 44 %, Δ R = 19 %, relaxation time ~ 10 ps, antiresonant resonant design for fiber laser mode-locking
passive heat sink	passive heat sink for fiber coupled SAM

SAM? - saturable absorber mirror λ = 2150 nm

product list λ = 2150 nm (2050 nm ... 2200 nm)

Part No.	Description	Data PDF
SAM-2150-8-10ps-x	SAM: λ = 2150 nm, absorbance 8 %, Δ R = 5 %, relaxation time ~ 10 ps

SAM? - saturable absorber mirror λ = 2400 nm

product list λ = 2400 nm (2350 nm ... 2600 nm)

SAM 2400 nm for mode-locking of a Cr²⁺:ZnSe laser

Part No.	Description	Data PDF
SAM-2400-1-10ps-x	SAM: λ = 2400 nm, absorbance 1 %, Δ R = 0.6 %, relaxation time ~ 10 ps
SAM-2400-1.5-10ps-x	SAM: λ = 2400 nm, absorbance 1.5 %, Δ R = 0.9 %, relaxation time ~ 10 ps

SAM? - saturable absorber mirror λ = 3000 nm

product list λ = 3000 nm (2000 nm ... 3200 nm)

SAM 3000 nm for mode-locking of a Cr²⁺:ZnSe laser

Part No.	Description	Data PDF
SAM-2900-9-10ps-x	SAM: λ = 2900 nm, absorbance 9 %, Δ R = 4 %, relaxation time ~ 10 ps
SAM-3000-33-10ps-x	SAM: λ = 3000 nm, absorbance 33 %, Δ R = 18 %, relaxation time ~ 10 ps
